คุณสมบัติและข้อมูลเชิงเทคนิค
1. เป็นอ่างน้ำควบคุมอุณหภูมิ โครงสร้างภายนอกและภายในตัวอ่างทำด้วยโลหะไร้สนิม
2. มีขนาดภายใน (ยาวxกว้างxสูง) 472x267x200 เซนติเมตร ความจุ 23.1 ลิตร
3. สามารถควบคุมอุณหภูมิภายในตัวอ่างได้ตั้งแต่ 5oC เหนืออุณหภูมิห้องถึง 100oC และจุดเดือดของน้ำ โดยมีค่าละเอียดในการตั้งค่าอุณหภูมิไม่เกิน 0.1oC
4. ควบคุมอุณหภูมิด้วยระบบ microprocessor PID Temperature แสดงค่าอุณหภูมิเป็นตัวเลขไฟฟ้า (LED)
5. สามารถตั้งให้เครื่องทำงานอย่างต่อเนื่อง
6. สามารถตั้งเวลาการทำงาน (hold) ได้ตั้งแต่ 1 นาที ถึง 99.59 ชั่วโมง
7. มีปุ่มหมุนเอนกประสงค์ สำหรับตั้งค่าอุณหภูมิ (temp) , หน่วงเวลา (delay) , และตั้งเวลา (hold)
8. มีระบบป้องกันอันตรายจากอุณหภูมิสูงเกินเป็นแบบปรับตั้งค่าและแสดงค่าเป็นตัวเลขไฟฟ้า (LED)
9. เมื่อระดับน้ำต่ำกว่ากำหนด จะมีสัญญาณเสียงและแสงแจ้งเตือน
10. มีฝาปิดลักษณะFlat cover 6 หลุม
11. เป็นผลิตภัณฑ์ของประเทศเยอรมัน
12. ใช้ไฟฟ้า 220 โวลท์ 50 เฮิร์ท
13. เป็นผลิตภัณฑ์ที่ได้รับการรับรองคุณภาพและความปลอดภัยตามมาตรฐานสากล ISO 9001
14. บริษัทมีเอกสารการเป็นตัวแทนจำหน่ายจากบริษัทผู้จำหน่ายภายในประเทศ
15. รับประกันคุณภาพ 1 ปี
Temperature
| Temperature sensor | digital temperature sensor, mounted on the outside of the bath |
| Temperature | Setting Celsius / Fahrenheit |
| Working temperature range | at least 5 above ambient to +100 (with cover, depending on ambient pressure) |
| Setting temperature range | +10 to +100 °C |
| Setting accuracy temperature | 0.1 °C |
Control technology
| Calibration | 2-point calibration |
| Controller | intuitive 3.5" colour graphic display with touch screen |
| Controller | digital display of set and actual temperature and of (remaining) programme time |
Safety
| Temperature control | two-stage safety system to prevent overtemperature (pressure sensor for level monitoring, thermal fuse for heating shutdown in case of error) |
| Temperature control | individually adjustable overtemperature alarm, visual and acoustic |
| Temperature control | Independent temperature limiter to switch off the heating in case of failure |
| Autodiagnostic system | microprocessor PID-temperature controller with integrated autodiagnostic system with fault indicator |
Heating concept
| Heating | corrosion-proof large-area heating on the outside of the interior |
Standard equipment
| Cover | Stainless steel gable cover |
| Drain system | innovative drain system - easy to empty |
| Timer | digital timer from 1 min. up to 99 hours 59 min., visual and acoustic |
Stainless steel interior
| Interior | Deep-drawn stainless steel tray (stainless steel W.St. 1-4301), without corners and edges for easy cleaning incl. central drain (no disturbing installations) |
| Dimensions | l(A) x w(B) x h(C): 472 x 267 x 200 mm |
| Volume | 23.1 l |
| Liquid level min. | 20 mm |
| Liquid level max. | 164 mm |
Textured stainless steel casing
| Dimensions | l(D) x w(E) x h(F2): 749 x 349 x 425 mm |
Electrical data
| Voltage Electrical load | 230 V, 50/60 Hz approx. 1420 W |
| Voltage Electrical load | 115 V, 50/60 Hz approx. 1420 W |
Ambient conditions
| Installation | The vent openings in the left and back side must remain unobstructed. The distance to the wall must be at least 100 mm on the sides and at least 150 mm to the rear. The minimum spacing from the top of the bath to the next ceiling is 750 mm. |
| Ambient temperature | +5 °C to +40 °C |
| Humidity rh | max. 80 %, non-condensing |
| Overvoltage category | II |
| Pollution degree | 2 |
| Water bath | |
Packing/shipping data
| Dimensions approx incl. carton | l x w x h: 849 x 449 x 525 mm |
| Transport information | The appliances must be transported upright |
| Customs tariff number | 8419 8998 |
| Country of origin | Federal Republic of Germany |
| WEEE-Reg.-No. | DE 66812464 |
| Net weight | approx. 20 kg |
| Gross weight carton | approx. 23 kg |
Ideal for the temperature control of ointments, emulsions, samples, plates and nutrient solutions in the labora
