คุณสมบัติและข้อมูลเชิงเทคนิค
1. The first cutting-edge USB data recording system. The data of the whole experiment process was automatically recorded.
2. U disk to record the whole process of experimental data (temperature, speed, time can be recorded).
3. Download data automatically tabulated to save and print. Mouse click to easily replay the experiment process. It is convenient to optimize reaction conditions, screen experimental methods, and confirm the experimental process.
4. Multi-section speed, temperature, time control system. A variety of different speed, temperature and time experimental modes can be set at one time, and the operation mode can be automatically changed during operation.
5. Super low speed start, the speed is out of control, automatic lock, adjustable starting speed. Unique dynamic balance design to ensure smooth operation.
6. Silent fan design, forced convection mode and unique air duct design ensure good temperature uniformity.
7. Automatic refrigeration mode, using environmentally friendly refrigerant, can automatically adjust the opening and closing of the refrigeration system according to the change of environmental temperature, without manual operation. (Refrigeration type)
8. Intelligent refrigeration frost-free operation technology, automatic defrosting function, defrosting time and defrosting interval can be set freely, so that the equipment can run stably for a long time under low temperature. And has the refrigeration delay start function, effectively protect the compressor.(Refrigeration type)
9. Users can freely set three operation modes: forward, reverse and forward and reverse.
10. LCD liquid crystal display, temperature, time, speed with the interface display.
| Model | BJPX-1102D | BJPX-2102D |
| Capacity | 175L | |
| Temperature Control Range | Ambient temperature+5~65℃ | 4~65℃ (at 20℃) |
| Temperature Control Accuracy | ±0.1℃ | |
| Temperature Uniformity | ±0.5℃(at 37℃, effective working surface) | |
| Temperature Fluctuation | ≤0.1℃(at 37℃) | |
| Timing Range | 0~9999h/min(can be untimed, continuous operation) | |
| Control Mode | PID microcomputer control | |
| Display | LCD display | |
| Circulation Mode | Forced convection | |
| Oscillation Mode | Rotary shaking | |
| USB Data Download Processing System | YES | |
| Control System | Standard mode; Static mode; Persistent mode; Program control mode(multi-section temperature, speed, time control) | |
| Cyclotron Frequency Range | 0, 20~350rpm(can do static culture, cross or alternate operation) | |
| Cyclotron Frequency Accuracy | ±1rpm | |
| Swing Amplitude of The Plate | Φ26mm(Can be customized Ф35 (20-250rpm), Φ50 (20-200rpm) | |
| Refrigerant | / | R134a/210g |
| Max Capacity | Clamp flask:100ml*60 or 250ml*38 or 500ml*22 or 1000ml*16 Haftplatte: 100ml*60 or 250ml *36 or 500ml*24 or 1L*16 | |
| Defrost Function | / | Automatic defrosting |
| Auxiliary Function | Ultra-low speed start, Adjustable start speed, Over-speed automatic protection, Monitoring timer, Parameter memory, Call recovery, Refrigeration unit overload protection and call delay start(for BJPX-2102D), Upper and lower limit over-temperature sound and light alarm, Automatic stop upon opening door, Set parameters to check, Monitor temperature and ambient temperature correction. | |
| Material | External material: ABS; Internal material: Stainless steel | |
| Power Supply | Standard: AC220V, 50Hz Optional: AC220V, 60Hz; 110V, 50/60Hz(External transformer) | |
| Consumption | 600W | 850W |
| Shelves | 500*360mm, 2pcs | |
| Standard Accessories | Clamp flask: 250ml*24, Shelf*1 | |
| Optional Accessories | Lighting function, UV disinfection function, Printer, Haftplatte | |
| External Size(W*D*H)mm | 700*580*1280 | |
| Package Size(W*D*H)mm | 825*720*1490 | |
| Net Weight(kg) | 180 | |
| Gross Weight(kg) | 220 | |
ตู้บ่มเพาะเชื้อพร้อมเขย่าชนิดควบคุมอุณหภูมิ
